項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓
Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

引出線
#  of       Leads

轉動慣量Rotor Inertia

重量Weight

機身長度Length

單出軸
Single Shaft

雙出軸
Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

35BYG101

35BYG101B

7.5

0.3

25

20

5.5

0.4

4

7

0.09

20

35BYG103

35BYG103B

4.5

0.5

9

5

5.5

0.4

4

35BYG203

35BYG203B

6.24

0.48

13

8.8

9.0

0.65

4

10

0.11

26

35BYG208

35BYG208B

7.35

0.35

21

19

9.0

0.65

4

35BYG304

35BYG304B

12

0.25

48

25

9.7

0.7

6

11

0.12

28

35BYG307

35BYG307B

3.12

1.3

2.4

2.5

13.88

1.0

4

35BYG502

35BYG502B

10

0.4

25

17

13.88

1.0

6

14

0.16

34

35BYG504

35BYG504B

4.42

0.65

6.8

10

19.44

1.4

4
