項目Item

規(guī)格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環(huán)境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓
Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

引出線
#  of       Leads

轉動慣量Rotor Inertia

重量Weight

機身長度Length

單出軸
Single Shaft

雙出軸
Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

39BYG9004

39BYG9004B

6

0.6

10

15

16.7

1.2

4

19.5

0.16

32

39BYG9104

39BYG9104B

4

0.5

8

9.5

11.1

0.8

4

12

0.11

20

39BYG9403

39BYG9403B

12

0.4

30

60

22.2

1.6

4

25

0.2

35

39BYG9404

39BYG9404B

7.8

0.6

13

26

22.2

1.6

4

39BYG9703

39BYG9703B

9

0.6

15

26

30.6

2.2

4

43

0.28

46
