項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓
Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

引出線
#  of       Leads

轉動慣量Rotor Inertia

重量Weight

機身長度Length

單出軸
Single Shaft

雙出軸
Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

39BYG108

39BYG108B

3.63

0.55

6.6

7.5

11.1

0.8

4

11

0.11

20

39BYG111

39BYG111B

5.6

0.4

14

6.4

8.33

0.6

6

39BYG313

39BYG313B

3.36

0.8

4.2

3

15.3

1.1

6

18

0.16

32

39BYG318

39BYG318B

2.8

1.0

2.8

4.5

22.2

1.6

4

39BYG404

39BYG404B

14

0.4

35

40

30.5

2.2

4

23

0.2

35

39BYG425

39BYG425B

6.0

0.8

7.5

6.5

22.2

1.6

6

39BYG507

39BYG507B

4.0

1.0

4.0

7.0

34.7

2.5

4

28

0.22

38

39BYG513

39BYG513B

8.55

0.57

15

25

34.7

2.5

4

39BYG701

39BYG701B

11

0.5

22

27

38.9

2.8

4

38

0.28

46
