項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

引出線
#  of       Leads

轉動慣量Rotor Inertia

重量Weight

機身長度Length

單出軸
Single Shaft

雙出軸
Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

42BYG9001

42BYG9001B

4

0.95

4.2

3.2

22

1.58

6

38

0.22

34

42BYG9013

42BYG9013B

6

0.6

10

9.5

22

1.58

6

42BYG9017

42BYG9017B

6.6

0.55

12

25

30

2.2

4

42BYG9031

42BYG9031B

2.8

1.33

2.1

2.5

30

2.2

4

42BYG9102

42BYG9102B

2.8

1.68

1.65

3.8

50

3.6

4

55

0.28

40

42BYG9110

42BYG9110B

6

0.8

7.5

10

36

2.59

6

42BYG9115

42BYG9115B

4

1.2

3.3

4.1

36

2.59

6

42BYG9121

42BYG9121B

5.4

0.9

6

12

50

3.6

4

42BYG9403

42BYG9403B

4.2

1.2

3.5

8.5

62

4.4

4

80

0.35

48

42BYG9404

42BYG9404B

2.8

1.68

1.65

4.8

62

4.4

4

42BYG9407

42BYG9407B

6

0.8

7.5

9.2

44

3.17

6

42BYG9417

42BYG9417B

4

1.2

3.3

3.5

44

3.17

6
