項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

引出線
#  of       Leads

轉動慣量Rotor Inertia

重量Weight

機身長度Length

單出軸
Single Shaft

雙出軸
Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

42BYGH010

42BYGH010B

1.65

1.5

1.1

1.6

32

2.3

4

38

0.2

34

42BYGH013

42BYGH013B

4.0

0.95

4.2

2.5

22

1.58

6

42BYGH019

42BYGH019B

3.4

0.95

3.6

6.06

32

2.3

4

42BYGH054

42BYGH054B

8.2

0.6

13.6

7.8

22

1.58

6

42BYGH102

42BYGH102B

3.6

1.2

3.0

3.2

36

2.59

6

55

0.24

40

42BYGH113

42BYGH113B

5.4

0.85

6.3

10

50

3.6

4

42BYGH114

42BYGH114B

6.0

0.8

7.5

6.7

36

2.59

6

42BYGH150

42BYGH150B

2.8

1.68

1.65

3.2

50

3.6

4

42BYGH405

42BYGH405B

5.3

0.85

6.2

11

62

4.4

4

80

0.32

48

42BYGH416

42BYGH416B

6.0

0.8

7.5

6.3

44

3.17

6

42BYGH432

42BYGH432B

4.0

1.2

3.3

2.8

44

3.17

6

42BYGH450

42BYGH450B

2.8

1.68

1.65

2.8

62

4.4

4
