項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

引出線
#  of       Leads

轉動慣量Rotor Inertia

重量Weight

機身長度Length

單出軸
Single Shaft

雙出軸
Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

57BYGH9403

57BYGH9403B

4.06

1.4

2.9

8.5

76

5.5

4

120

0.45

42

57BYGH9404

57BYGH9404B

7.98

0.7

11.4

34

76

5.5

4

57BYGH9405

57BYGH9405B

5.7

1.0

5.7

8.5

54

3.9

6

57BYGH9503

57BYGH9503B

2.32

2.8

0.83

3.5

100

7.2

4

275

0.65

52

57BYGH9505

57BYGH9505B

4.62

1.4

3.3

14

100

7.2

4

57BYGH9506

57BYGH9506B

3.3

2

1.65

3.5

69

5.0

6

57BYGH9605

57BYGH9605B

2.24

2.8

0.8

4.5

111

8.0

4

300

0.7

56

57BYGH9610

57BYGH9610B

4.48

1.4

3.2

18

111

8.0

4

57BYGH9611

57BYGH9611B

3.2

2

1.6

4.5

76

5.5

6

57BYGH9704

57BYGH9704B

8.6

1.0

8.6

23

180

13

6

480

1

76

57BYGH9715

57BYGH9715B

6.02

1.4

4.3

23

250

18

4

57BYGH9716

57BYGH9716B

12.04

0.7

17.2

92

250

18

4
