項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

引出線
# of Lead

接線方式　Connection

電壓Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩　Holding　　　 Torque

轉動慣量Rotor Inertia

重量Weight

機身長度Length

Uni-P.

Bi-Polar

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

86BYG103-8A

8

*

3.38

1.8

1.88

7

194

14

620

1.6

62

S

4.7

1.25

3.76

28

278

20

P

2.35

2.5

0.94

7

278

20

86BYG205-8A

8

*

3

4

0.75

3.5

389

28

1200

2.2

90

S

4.2

2.8

1.5

14

555

40

P

2.1

5.6

0.375

3.5

555

40

86BYG403-8A

8

*

5

1.25

4

17

333

24

760

1.7

69

S

7.2

0.9

8

68

472

34

P

3.6

1.8

2

17

472

34

86BYG502-8A

8

*

3.36

2.8

1.2

4.8

315

22.6

900

1.8

75

S

4.8

2

2.4

19.2

444

32

P

2.4

4

0.6

4.8

444

32
