項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

引出線
# of
Lead

接線方式Connection

電壓Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

轉動慣量Rotor Inertia

重量
Weight

機身
長度
Length

Uni-P.

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

86BYGH101-8A

8

*

4.2

3.5

1.2

4.5

555

40

2300

3.2

97

S

6

2.5

2.4

18

778

56

P

3

5

0.6

4.5

778

56

86BYGH450-8A

8

*

4.6

2

2.3

10

305

22

1400

2.2

76

S

6.44

1.4

4.6

40

430

31

P

3.22

2.8

1.15

10

430

31

86BYGH450A-8A

8

*

3.38

4.5

0.75

4.6

611

44

2700

3.7

113

S

4.8

3.2

1.5

18.4

861

62

P

2.4

6.4

0.38

4.6

861

62

86BYGH450B-8A

8

*

5.04

4.2

1.2

7.5

889

64

4000

5.2

151

S

7.2

3.0

2.4

30

1250

90

P

3.6

6.0

0.6

7.5

1250

90
