項目Item

規格Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓
Rated Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding
 Torque

最大
推力
Push  Torque

步長
Linear Travel
Per step

引出線
#  of       Leads

轉動慣量
Rotor
 Inertia

重量Weight

機身長度Length

V

A

W

mH

Oz-in

Kg.cm

Kg

mm

g-cm2

Kg

mm

57BYGH414-TL

2.8

2

1.4

1.4

54

3.9

91

0.01

6

120

0.45

42

57BYGH518-TL

2.3

2.8

0.83

3.0

140

10

4

275

0.65

52

57BYGH614-TL

2.5

2.8

0.9

3.7

175

12.5

4

300

0.7

56

57BYGH702-TL

3

3

1

2.2

187

13.5

6

480

1

77
