Item

Specifications

步距角精度Step Angle Accuracy

± 5% (full step, no load)

電阻精度Resistance Accuracy

± 10%

電感精度Inductance Accuracy

± 20%

溫升Temperature Rise

80°C Max. (rated current, 2 phase on)

環(huán)境溫度Ambient Temperature

- 10°C ~ +50°C

絕緣等級Insulation Class

B

介電強度Dielectric Strength

500 VAC for one minute

轉軸徑向跳動Shaft Radial Play

0.06 Max. (450 g-load)

轉軸軸向跳動Shaft Axial Play

0.08 Max. (450 g-load)

型號
Model No.

電壓
Rated
Voltage

電流
Current

電阻
Resistance

電感
Inductance

最大靜力矩Holding Torque

引出線
#  of       Leads

轉動慣量Rotor Inertia

重量Weight

機身長度Length

單出軸
Single Shaft

雙出軸
Double Shaft

V

A

W

mH

Oz-in

Kg-cm

g-cm2

Kg

mm

60BYGH101W

60BYGH101W-B

6.97

1.7

4.1

7.4

62.5

4.5

3

170

0.5

42

60BYGH603W

60BYGH603W-B

7.5

1.5

5

10

113.9

8.2

3

280

0.7

56

60BYGH6201W

60BYGH6201W-B

2.1

3

0.7

2

216.7

15.6

3

530

0.9

85

60BYGH902W

60BYGH902W-B

1.72

5.2

0.33

0.55

236

17

3

570

1.0

90
